Central wavelength (nm)

488±5

Operating mode

CW

Output power (mW)

>50, 60, … , 300

>300, 200, … , 1500

Power stability (rms, over 4 hours)

<3%, <2%, <1%, <0.5%

Transverse mode

Near TEM00

Multimode

M2 factor

<1.5 (<1.2, optional)

/

Beam diameter at the aperture (1/e2,mm)

~3.0 (~ 1.2, optional)

~3.0×3.0

Beam divergence, full angle (mrad)

~ 1.0

~2.5×1.0

Polarization ratio

>50:1 (>100:1, optional)

Horizontal±5 degree (Vertical Optional)

>50:1

Horizontal±5 degree (Vertical Optional)

Warm-up time (minutes)

<5

Beam height from base plate (mm)

24.8

Operating temperature (℃)

10~35

Power supply

85-264VAC

PSU-III-LED/ PSU-III-FDA (Frequency for 1Hz-30kHz)

100-240VAC

PSU-A-D (Frequency for 30kHz -100kHz)

Modulation optional

TTL on/off, 1Hz-1kHz, 1kHz-10kHz, 10kHz-30kHz, 30kHz-100kHz; and Analog modulation optional

Expected lifetime (hours)

10000

Warranty

1 year
